Bend-Tech PRO Sheet Metal Bundle

Bend-Tech PRO Software Sheet Metal Bundle

Bend-Tech’s Pro software will allow you to:

  • Full 3D assembly design
  • Precise tube bending instruction including springback.
  • Cutting profile instructions; fish-mouthing, notching, etc.
  • Includes all features of Bend-Tech EZ, EZ3D, and more!

$405.00

Description

Bend-Tech PRO – Sheet Metal Bundle

Modules included in the Sheet Metal Bundle  include:

  • Sheet Metal Designer
  • MSP Templates

After the Purchase:

Confirmation Email

You will receive a confirmation receipt email after a successful transaction.

Download Link

Download link will be provided through your given email within 1-2 hours during our normal business hours. (If you do not receive our email, check your spam/junk mail.)

CD Shipment

Your CD will be shipped out of our facility within the next normal business day through USPS and should arrive within 5 business days for domestic (USA) shipping.

Computer Requirements:

Minimum Requirements

  • Windows Operating System (XP, Vista, 7, 8, 8.1, 10, 11). For Mac, you will need Windows OS running on Emulator. (i.e: Boot Camp, Parallels, and VMware.)
  • 1 GHz processor.
  • 2 GB RAM (Memory).
  • 1 GB hard drive space.
  • 1024 x 768 screen resolution.
  • OpenGL 1.3 compatible graphics card.
  • .NET framework 3.5 installed.
  • Keyboard and mouse.
  • Active internet connection (Internet connection is needed during the first activation and then every 6 months, the software can run offline in between.)

Recommended Requirements

  • Windows Operating System (7, 8, 8.1, 10). For Mac, you will need Windows OS running on Emulator. (i.e: Boot Camp, Parallels, and VMware.)
  • 1 GHz processor.
  • 4 GB RAM (Memory).
  • 1 GB hard drive space.
  • 1280 x 800 screen resolution or greater.
  • OpenGL 1.3 compatible graphics card.
  • .NET framework 3.5 SP1 installed.
  • PDF reader installed (For help guides).
  • Full keyboard and mouse.
  • CD Drive (For installation from a CD).
  • High-speed internet.
